Heavy-Duty Industrial Fabric Die Cutter

Understanding the BP Series Fabric Die Cutting Machine

The BP series fabric die cutting machine is an industrial-grade automatic cutting solution designed by AOTOBOT to handle heavy-duty and diverse materials. Covering models B1-1013, B1-1815, B1-2516, and B1-2518, this machine integrates intelligent control, high precision, and safety features. It is specialized in cutting materials for sofa, medical, and body armor production, meeting the strict requirements of industrial-scale manufacturing.

Product Parameters of BP Series Fabric Die Cutting Machine

Parameter	Specification
Model Options	B1-1013, B1-1815, B1-2516, B1-2518
Effective Work Area (L×W)	B1-1013: 1000×1300mm; B1-1815: 800×1500mm; B1-2516: 2500×1600mm; B1-2518: 2500×1800mm (customizable)
Cutting Thickness	≤30mm
Cutting Speed	300~800mm/s
Cutting Precision	≤0.1mm
Repeat Accuracy	≤0.1mm
Fixing Method	Vacuum suction
Driving System	Intelligent digital control servo system
Command Compatibility	DXF, HPGL compatible format
Power Supply	AC220/380V 50~60HZ
Suction Power	1.5KW - 9KW (variable frequency air pump optional)
Working Environment	Temperature: -10ºC~40ºC; Humidity: 20%~80% RH
Machine Dimensions	2300×800×1700mm (standard)
Standard Tools	Driven rotary tool, Cursor, Pen
Optional Tools	Electric oscillating tool, Projector system, Camera
Warranty	1 year
Certification	CE, ISO



Functionality of the BP Series Industrial Fabric Die Cutter

Automatic Nesting & Continuous Feeding

The built-in automatic nesting system optimizes material layout, reducing waste by up to 15% and saving production time. The conveyor table enables continuous feeding, supporting ultra-long cutting without limitations from table length, ideal for large-area materials like carpets and sofa fabrics.

Advanced Safety & Control

Equipped with a 360° infrared sensing system and physical anti-collision mechanism, the machine ensures operator safety during high-speed operation. The multi-language LCD touch panel simplifies parameter setting and operation, suitable for global production teams.

High-Precision Fixing & Cutting

The honeycomb aluminum plate platform provides strong vacuum suction and long-lasting flatness, firmly fixing materials of different thicknesses. Imported linear guides and servo motors deliver stable performance, achieving cutting precision of ≤0.1mm to meet industrial quality standards.

Characteristic Advantages of the BP Series Fabric Die Cutting Machine

Superior Precision & Efficiency

With cutting and repeat accuracy of ≤0.1mm, the BP series excels in processing high-precision industrial materials. The cutting speed of 300~800mm/s significantly boosts production efficiency, supporting large-volume orders in industries like sofa manufacturing and medical textile processing.

Wide Material Compatibility

This industrial fabric die cutting machine handles a wide range of materials, including knitted/woven fabric, PU leather, Oxford cloth, canvas, sponge, cotton & linen, and specialized materials for body armor and medical products. It’s a one-stop solution for multiple industrial sectors.

Durability & Reliability

Imported servo motors and linear guides ensure long machine life and stable performance even under heavy-duty operation. All products are CE and ISO certified, exceeding domestic standards and meeting international quality requirements.

Customization & Flexibility

The BP series offers customizable work areas to fit specific production needs. Optional tools like the projector system and camera support visual positioning cutting, expanding application scenarios for complex materials.

Applications of the BP Series Industrial Fabric Cutter

The BP series fabric die cutting machine is widely applied in:

Sofa and furniture production (fabric, leather, and sponge cutting)

Medical industry (specialized medical fabric processing)

Body armor manufacturing (high-strength synthetic and bulletproof material cutting)

Clothing and luggage production (knitted/woven fabric, PU leather cutting)

Mat and carpet industry (large-area continuous cutting)

Industrial textile processing (coating fabric, canvas handling)

FAQ About the BP Series Fabric Die Cutting Machine

What is the core advantage of the BP series?

Our cutting technology originated from Japan 40 years ago, with products sold to over 80 countries. The BP series features a patented double blade plate (doubling cutting speed), YASAKAWA motor, and intelligent servo system, ensuring high precision and efficiency for industrial use.

Can the machine handle thick materials?

Yes, the BP series supports cutting thickness up to 30mm, making it suitable for thick materials like sofa sponge, canvas, and body armor fabrics.

Is on-site training provided?

Yes, our professional after-sales team (engineers with over 10 years of experience) provides on-site installation and training. Global distributors also offer daily after-sales support.

Are the machine parameters customizable?

Yes, the effective work area and suction power are customizable. We also offer optional tools like electric oscillating tools and camera systems to meet specific production requirements.
