Product Parameters
| Machine type | M11 | Remarks |
| Feature | Name | AOTOBOT | |
| Cutting width | 1650 | |
| Cutting length | 3300 | |
| Maximum Cutting height | 75mm | |
| Cutting specification | Methods | Straight knife reciprocating clipping | |
| Knives | Automatic sharpening, Knife width 8mm Thickness 2.0, 2.5mm | |
| Speed | Top speed 45m / min | |
| Accuracy | ± 1mm | |
| Drills | Solid 1.6, 2, 3mm | Specification for hollow drilling 4-20mm. Selection |
| Machine specification | Outside dimensions of machine | length width and height 7100*2300*1400mm | |
| Conveyor area | length and width 2450*2100mm | Optional custom length 3000 / 3500mm |
| Vacuum method | separate frequency conversion adsorption | |
| Operate the computer | pc desktop computer | |
| System specification | language | Chinese ,English | |
| Power | Three phase 380V , 22KW | |
| Others | Compressed air | -20KP | |
| Standard color | White/Grey | |
| Weight | 4000KG | |
| Option | Selection, Knife cooling, Device movement | |
Product Description
Specification
The M11 ships with a complete set of smart functions ready to run:
Automatic covering film — lays a protective layer over fabric surfaces during the cut cycle.
Automatic positioning and drilling — aligns markers precisely for multi-ply cutting operations.
Automatic cleaning bristle device — keeps the vacuum table free of debris, maintaining consistent suction.
Automatic air float linkage — reduces friction during fabric feeding, minimizing drag on lightweight materials.
Automatic grinding & blade change indicator — signals when knife maintenance is required, taking the guesswork out of blade scheduling.
Separate vacuum pump with multi-section control — activates only the zones under the cutter, saving energy on narrower materials.
Automatic fault detection indicator — pinpoints issues quickly to minimize diagnostic time.
Transverse machine movement — allows a single cutter to serve multiple cutting stations, increasing machine utilization.
What Can This CNC Cutting Machine Do? (Applications)
The M11 handles a wide range of soft materials across multiple industries:
General Apparel – Cuts cotton, polyester blends, knits, and light coatings. Replaces manual layering with consistent, repeatable output.
Automotive & Sofa Upholstery – Cuts seat covers, headliners, and upholstery fabrics. Vacuum holds multi-layer stacks flat to prevent edge mismatches.
Medical & Industrial Textiles – Processes nonwovens, technical fabrics, and composites with the same ±1mm precision – no recalibration needed.
Small Batch & Custom Production – Short runs, custom sizes, extended conveyor (up to 3500mm), and hollow drilling (4‑20mm) – adapts to your workflow.
Company Profile
![CNC Cutting Machine Uses]()
Why Choose AOTOBOT as Your CNC Cutting Machine Manufacturer?
Choosing a cutting machine manufacturer is about more than specs – it‘s about finding a partner who understands your production realities.
We start with your material, not a template. Tell us your fabric types, stack heights, and daily volume. We‘ll recommend the right model (M11, M21, or custom) – not the one we need to push.
One supplier across the soft material spectrum. Garments, auto interiors, medical textiles, industrial fabrics – even glass fiber and bulletproof composites. No need to manage five different vendors.
Factory-direct pricing with real local support. No middleman markup. We have a branch in Vietnam and distributors in Germany, the US, Brazil, India, and elsewhere – installation and service come from people near you.
We customize to your workflow. Need a longer conveyor (3000‑3500mm), hollow drilling (4‑20mm), or knife cooling? Just describe your setup. We adjust the machine to fit your line.
Ready to move beyond generic brochures? Share your material specs – we‘ll send a clear machine recommendation and a quote.
![CNC Cutting Machine Uses]()
![CNC Cutting Machine Uses]()
![CNC Cutting Machine Uses]()
![CNC Cutting Machine Uses]()
Q1. Are you a factory or a trading company?
(ZHEJIANG BOPAI INTELLIGENT TECHNOLOGY CO., LTD.)is a national high-tech enterprise specializing in the design, research and development, production, sales and service of intelligent cutting equipment. We have more than 15 years of manufacturing experience, and our products
were exported to more than 80 countries and regions.
Q2. Where is the advantage of your machine ?
Our cutting system technology developed from Japan since 40 years ago, till now , we have sold to
More than 40 countries.
Aotobot brand cutting machine equipped with all the specifications . Bopai company appled the Patent of double knife plate which hugely improved the cutting speed by double time. Aotobot equipment supply YASAKAWA motor and drive system,
Adsorption device, bristle cleaning automatically,air cooling system, knife intelligence technology etc.
Q3. how about the installation and after sale service?
A: we have one strong and professional after sale service team,all the engineers with more than 10 years experiences. We can send technical to supply training and installation. Also we have distributors in all over the world, which also can take care of the after sale service daily.
Q4. How do you guarantee your quality?
A: With more than 40years of manufacturing experience, our products are
superior to the domestic standard and meet the Japan standard. All the main device are
Importing from Japan . machines run well without confusion on problem.
