Value for Multi-Layer Processing
In industries like apparel and upholstery, where bulk cutting is essential, this machine replaces labor-intensive manual cutting, reducing errors and slashing production time. Its ability to handle multiple layers simultaneously makes it a cost-effective solution for businesses scaling up operations.
| Machine type | M10 | Remarks |
| Feature | Name | AOTOBOT | |
| Cutting width | 1650 | |
| Cutting length | 3300 | |
| Maximum Cutting height | 75mm | |
| Cutting specification | Methods | Straight knife reciprocating clipping | |
| Knives | Automatic sharpening, Knife width 8mm Thickness 2.0, 2.5mm | |
| Speed | Top speed 45m / min | |
| Accuracy | ± 1mm | |
| Drills | Solid 1.6, 2, 3mm | Specification for hollow drilling 4-20mm. Selection |
| Machine specification | Outside dimensions of machine | length width and height 7100*2300*1400mm | |
| Conveyor area | length and width 2450*2100mm | Optional custom length 3000 / 3500mm |
| Vacuum method | separate frequency conversion adsorption | |
| Operate the computer | pc desktop computer | |
| System specification | language | Chinese ,English | |
| Power | Three phase 380V , 22KW | |
| Others | Compressed air | -20KP | |
| Standard color | White/Grey | |
| Weight | 4000KG | |
| Option | Selection, Knife cooling, Device movement | |
Functionality: How Does the M10 Series Operate?
Reciprocating Straight Knife Operation
The core straight knife reciprocating clipping system features an automatically sharpening knife (8mm width, 2.0/2.5mm thickness) that delivers clean, fast cuts. With a top speed of 45m/min, it processes stacks of fabric efficiently, while solid drills (1.6/2/3mm) and optional hollow drills (4-20mm) support hole punching for buttons and fasteners.
Vacuum Adsorption & Conveyor System
The separate frequency conversion adsorption provides adjustable vacuum pressure, securing multi-layer stacks to prevent shifting. The spacious conveyor area (2450*2100mm, customizable to 3000/3500mm) enables continuous feeding, supporting non-stop production.
Intelligent Control & Auxiliary Functions
Operated via a PC desktop computer (Chinese/English interface), it integrates seamlessly with production workflows. Key features include automatic covering film, automatic positioning and drilling, and automatic bristle cleaning—reducing manual intervention and boosting efficiency.
Durability & Maintenance Design
A new crankshaft cutter conveyor reduces noise and increases cutting strength, with fewer vulnerable parts. An automatic indicator for grinding and blade changing alerts operators to maintenance needs, minimizing downtime.
Specification
Automatic covering film
Automatic positioning and drilling
Automatic cleaning bristle device
Automatic air float linkage device
Automatic indicator for grinding and blade changing
Separate vacuum pump and multi-section control
Automatic indicator for fault detection
The cutting machine can move transversely to meet multi-lines of cutting work areas.etc
Function Feature
Vacuum
The vacuum adsorb pressure is stronger , exhaust decompression and cooling Chamber design
New crankshaft
New crankshaft cutter cutting conveyor , lower noise , higher cutting strength ,less vulnerable parts
Double blade plate
Double blade plate design , more stable cutting accuracy , more accurate cutting of lightand thin impermeable fabrics
Characteristic Advantages: What Sets the M10 Series Apart?
High Speed & Capacity
With a top speed of 45m/min and maximum cutting height of 75mm, it outperforms standard cutters for multi-layer cropping. This makes it ideal for bulk orders, slashing production cycles.
Precision & Stability
Boasting ±1mm accuracy, it ensures consistent cuts across all layers. The double blade plate design enhances stability, especially for lightweight, impermeable fabrics prone to slippage.
Customization & Adaptability
Optional knife cooling and device movement allow transverse machine adjustment, adapting to multi-line cutting work areas. It operates on 380V three-phase power (22KW), suitable for industrial setups.
Comprehensive Safety & Reliability
All main components are imported from Japan, meeting Japanese quality standards. The automatic fault detection indicator quickly identifies issues, simplifying troubleshooting.
Application Areas: Industries Benefiting from the M10 Series
Cuts multi-layer knitted fabric and woven fabric for shirts, pants, and jackets, streamlining bulk order processing for fashion brands and manufacturers.
Processes sofa seat fabrics, cushion materials, and curtain fabrics in large batches, ensuring uniform cuts for consistent product quality.
Cuts car seat covers, door panels, and headliners from synthetic and upholstery materials, balancing durability and precision for automotive manufacturers.
Handles glass fiber, aerospace materials, and bulletproof materials—thanks to its robust cutting power and stability, meeting strict industrial standards.
