Product Parameters
| Machine type | M10 | Remarks |
| Feature | Name | AOTOBOT |
|
| Cutting width | 1650 |
|
| Cutting length | 1900 |
|
| Maximum Cutting height | 75mm |
|
| Cutting specification | Methods | Straight knife reciprocating clipping |
|
| Knives | Automatic sharpening, Knife width 8mm Thickness 2.0, 2.5mm |
|
| Speed | Top speed 45m / min |
|
| Accuracy | ± 1mm |
|
| Drills | Solid 1.6, 2, 3mm | Specification for hollow drilling 4-20mm. Selection |
| Machine specification | Outside dimensions of machine | length width and height 5200 *2300 *1400mm |
|
| Conveyor area | length and width 2450*2100mm | Optional custom length 3000 / 3500mm |
| Vacuum method | separate frequency conversion adsorption |
|
| Operate the computer | pc desktop computer |
|
| System specification | language | Chinese ,English |
|
| Power | Three phase 380V , 22KW |
|
| Others | Compressed air | -20KP |
|
| Standard color | White |
|
| Weight | 4000KG |
|
| Option | Selection, Knife cooling, Device movement |
|
Functionality of the Textile Industrial Cutter
Core Cutting Functions
The machine adopts a straight knife reciprocating clipping method, equipped with automatic sharpening knives with widths of 8mm and thicknesses of 2.0mm or 2.5mm. It is also equipped with solid drills of 1.6mm, 2mm, 3mm, and hollow drills with a specification range of 4 - 20mm, which can meet different drilling and cutting requirements of various fabrics.
Auxiliary Intelligent Functions
It has a series of intelligent auxiliary functions, including automatic covering film, automatic positioning and drilling, and automatic cleaning bristle device, which greatly reduces manual operation steps. The automatic air float linkage device ensures the smooth conveying of fabrics during the cutting process, while the automatic indicator for grinding and blade changing and automatic indicator for fault detection can remind operators of maintenance and troubleshooting in a timely manner. In addition, the machine can move transversely, adapting to multi - line cutting work areas.
Characteristic Advantages of the Multi Layer Cutting Machine
Superior Vacuum Adsorption System
The machine is equipped with a separate frequency conversion adsorption vacuum system. Its enhanced vacuum adsorption pressure, combined with the exhaust decompression and cooling chamber design, can firmly fix multi - layer fabrics, ensuring cutting accuracy and avoiding fabric displacement during the cutting process.
High - Performance Mechanical Structure
The adoption of a new crankshaft cutter cutting conveyor reduces noise, improves cutting strength, and reduces the wear of vulnerable parts. The double blade plate design is a patented technology of Bopai Company, which not only improves cutting stability but also ensures more accurate cutting of light and thin impermeable fabrics, doubling the cutting speed compared with traditional equipment.
Reliable Configuration and Customization
It is equipped with a YASKAWA motor and drive system, which guarantees stable operation. The machine also supports customization services, such as optional custom conveyor area length of 3000mm or 3500mm, to meet the personalized needs of different customers.
Specification
Automatic covering film
Automatic positioning and drilling
Automatic cleaning bristle device
Automatic air float linkage device
Automatic indicator for grinding and blade changing
Separate vacuum pump and multi-section control
Automatic indicator for fault detection
The cutting machine can move transversely to meet multi-lines of cutting work areas.etc
Function Feature
Vacuum
The vacuum adsorb pressure is stronger , exhaust decompression and cooling Chamber design
New crankshaft
New crankshaft cutter cutting conveyor , lower noise , higher cutting strength ,less vulnerable parts
Double blade plate
Double blade plate design , more stable cutting accuracy , more accurate cutting of lightand thin impermeable fabrics
FAQ
Are you a factory or a trading company?
We are a national high - tech enterprise specializing in the design, R & D, production, sales, and service of intelligent cutting equipment, with more than 15 years of manufacturing experience. Our products are exported to more than 80 countries and regions.
Where is the advantage of your machine?
Our cutting system technology originates from Japan with a 40 - year history. The double blade plate patent technology doubles the cutting speed. The machine is equipped with high - quality components such as the YASKAWA motor and drive system, automatic cleaning bristle device, and air cooling system, ensuring its superior performance.
How about the installation and after - sale service?
We have a professional after - sales service team, whose engineers have more than 10 years of experience. We can send technicians to provide on - site training and installation. We also have distributors worldwide to provide daily after - sales service support.
How do you guarantee your quality?
With over 40 years of manufacturing experience, our products meet Japanese standards and are superior to domestic standards. All main devices are imported from Japan, ensuring the stable operation of the machines.
